10-2
COPYRIGHT © 1999 CANON INC. CANON GP605/605V REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 10 SIDE PAPER DECK
Figure 10-101b
2. Inputs to the Side Deck Driver Input (2/2)
Side deck driver PCB
+24VU.
J101-1
-3
-2
Copier
+5VR
Deck open
switch
Deck open
indicator
SW100
LED100
J3-1
-2
-3
-4
DOPN* When SW100 is pushed to open
the deck, '0'.
J103-4
-3
-2
-1
Deck open
detecting switch
SW101
J22-1
-2
DOPD*
When the deck is open, '0'.
(When SW101 is not pushed.)
J109-3
-1
Deck lifter lower
limit detecting
switch
SW102
J102-1
-2
DLLD
When the deck lifter is at the
lower limit, '1'.
(When SW102 is not pushed.)
J107-8
-7
Open switch PCB
DOLON*
NO
NO
0VU
Power supply
+38VU
When the deck is open/closed,
'0'.
(The LED turns on or flashes
while the deck lifter motor is
rotating.)
