CHAPTER 1 GENERAL DESCRIPTION
1-24
COPYRIGHT
©
1999 CANON INC. CANON GP605/605V REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
DANGER-
Laser radiation when open
and interlock defeated.
AVOID DIRECT EXPOSURE
TO BEAM.
FS6-8821
Figure 1-603-1 Label on the 100/120-V Model
C. Handling the Laser Assembly
Be sure to take extra care whenever servicing areas around the copier’s laser assembly, as by
avoiding the insertion of any tool having a high reflectance.
Be sure also to remove any watches and rings. They can reflect the laser beam to damage your
eyes during work.
The copier’s laser beam is a red light. Any covers that may reflect the laser beam bear a copy of
the label shown in Figure 1-603. Exercise particular caution whenever servicing behind such cov-
ers.
You will find the label on the copier's laser scanner covers from which laser light can escape.
