VIII . SERVICE MODE
A. Outline
The service mode screen configuration has a 3-layer construction: Initial screen, Level 1/Level
2 screen, and Level 3 screen.
Figure 13-A801 Configuration of the Screens
Initial screen
Level 1/Level 2
screen
Level 3
Item screen
Level 3
Item screen
Level 3
Item screen
User screen
From Level 1/
Level 2 screen
Reset key
Previous/Next
page
Previous/Next
page
Previous/Next
page
( )(2,8)( )
Reset key
Select a Level 1 item at the top of the screen;
then, select a Level 2 item.
Level 3
Item screen
Select an item.
