CHAPTER 13 TROUBLESHOOTING
13-118
COPYRIGHT
©
1999 CANON INC. CANON GP605/605V REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
V . TROUBLESHOOTING FEEDING PROBLEMS
A. Copy Paper Jams
Jams tend to be limited to the following blocks of the copier:
[1] Pickup assembly
[2] Separation/feeding assembly
[3] Fixing/delivery assembly
[4] Drum cleaner unit
[5] Reversing assembly
[6] Duplexing feeding assembly
The troubleshooting procedures that follow are organized according to location.
The copier is designed to indicate the location and type of each jam in its service mode
(COPIER>DISPLAY>JAM).
Figure 13-501
[1]
[2]
[3]
[4]
[5] [6]
