COPYRIGHT
©
1999 CANON INC. CANON GP605/605V REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
13-41
CHAPTER 13 TROUBLESHOOTING
1 After Replacing the CCD Unit
G. Electrical Parts
1) Check to make sure that the data lamp on the control panel is off, and turn off the main power
switch.
2) Disconnect the power plug.
Caution:
The copier remains powered as long as it is connected to the power outlet even after the main
power switch has been turned off. Be sure to disconnect the power plug.
3) Replace the CCD unit.
4) After mounting, connect the power plug to the power outlet, and turn on the main power switch
and the control panel power switch.
5) Execute COPIER>FUNCTION>CCD>CCD-ADJ in service mode.
6) Record the new values when all items of COPIER>ADJUST>CCD and the data of
COPIER>ADJUST>LAMP>L-DATA have been updated.
To Next Page
