CHAPTER 7 PICK-UP/FEEDING SYSTEM
7-76
COPYRIGHT © 1999 CANON INC. CANON GP605/605V REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
[1]
Figure 7-E806
2. Removing the Fixing Feeding Unit
Releasing lever Sensor
1) Slide out the fixing feeding unit from the
copier.
2) Detach the fixing feeding unit front cover.
3) Release the claw of the fixing feeding unit
releasing lever sensor [1].
