CHAPTER 7 PICK-UP/FEEDING SYSTEM
[6]
[7]
[8]
Figure 7-C805
4) Remove the E-ring [6] at the front of the
roller shaft; then, move the bearing [7] to
the center, and detach the vertical path
roller 2 [8].
