10-15
CHAPTER 10 SIDE PAPER DECK
Table 10-102
b. Switching the Motor Rotation Speed
To accommodate future copiers, the deck is equipped with a mechanism that automatically
switches pickup/feeding speed, in response to and based on combinations of the speed switch sig-
nals (DBIT 0, DBIT 1) from the copier's DC controller to the side deck driver PCB.
The combinations of the speed switch signals are as shown in Table 10-102. (In the case of the
host copier, the motor rotates at high speed.)
Rotation speed
High speed
Medium speed
Low speed
DBIT 0
L
H
L
DBIT 1
L
L
H
Speed switch signal
