Case 1121F - Instrument Cluster; Overview

3-CONTROLSANDINSTRUMENTS
INSTRUMENTCLUSTER
Overview[60630240]
RCPH10WHL583GAH1
Instrumentpanelindicators
TheinstrumentclusterwillcheckeachmonitoredsystemwhenyouturnthekeyswitchtotheONposition.AllLight
EmittingDiodes(LED)willilluminate,andthewarningalarmwillsoundforthreeseconds.Attheendofthischeck
allmonitoredsystemswillreturntonormaloperation.Ifthereisanopencircuitbetweenasensorandtheinstrument
clusteronsomecircuits,theLEDwillashandthewarningalarmwillsoundfor5seconds.
1.Four-wayasherandturnsignalindicator
Theindicatorlampswillashwhenaturnissignaledorwhenthefour-wayashersareactivated.
2.Brakepressureindicator
Theindicatorilluminateswhenthebrakesystempressureistoolow.Thealarmsoundscontinuously,
andthestopmasterindicatorwillbered.Stopthemachine,andcorrecttheproblem.
3.Lampindicator
TheindicatorilluminateswhenthedrivinghighbeamlampsareON.
4.Secondarysteering(ifequipped)
Thisindicatorilluminateswhentheprimarysteeringsystempressureistoolow.Thealarmsounds
continuouslyandthestopmasterindicatorturnsred.
Ifthissituationoccurs,stopthemachineimmediatelyandcontactyourdealer.
5.Parkingbrakeindicator
Thisindicatorilluminateswhentheparkingbrakeisapplied.
3-35
