Case 1121F - Operators Seat

3-CONTROLSANDINSTRUMENTS
OPERATOR'SSEAT
Overview[60627250]
WARNING
Lossofcontrolhazard!
DONOTmakeseatadjustmentswhilethemachineisinmotion.Allseatadjustmentshouldbemade
withthemachinestationaryandtheparkingbrakeapplied.
Failuretocomplycouldresultindeathorseriousinjury.
W0293A
Standardoperator'sseat
1.Lumbaradjustmentknob-Turntheknobclockwiseto
increasethelumbarsupport.Turntheknobcounter-
clockwisetodecreasethelumbarsupport.
RCPH10WHL087BAL1
2.Armrestheightcontroladjustment-Turntheknobto
raiseorlowerthearmresttothedesiredposition.
NOTE:Eacharmrestwillpivottotheupposition.
RCPH10WHL085BAL2
3.Reclineradjustmenthandle-Liftuponhandle,move
thebackresttothedesiredposition,releasethehandle
tolockinposition.
RCPH10WHL084BAL3
3-3
