Case 1121F - Pedal Controls

3-CONTROLSANDINSTRUMENTS
Pedalcontrols[60628571]
Brakepedal
Thebrakepedalwillactuatethemachinebrakeswhen
pushed.
NOTE:Thepedalwillworkinconjunctionwiththetrans-
missiondeclutchswitchorPOWERINCHformoreef-
cientbraking.SeeDeclutchSwitchinOperatingInstruc-
tions-Chapter4forfurtherinformation.
NOTICE:Onsteepslopesusingthedownshiftmodeof
thetransmissionisrecommendedtoaidbrakingandto
helppreventbrakeoverheatingandprematurediscwear.
NOTE:Whenthemachineisshutoff,theparkingbrake
isautomaticallyset.
RCPH10WHL435AAH1
Rightsidebrakepedal(optional)
Anadditionalrightbrakepedalcanbeadded,allowing
boththeleftandrightpedaltobelockedtogether.Braking
canbeperformedfromeitherpedal.
RCPH10WHL492AAH2
FootThrottle
Pushthefootthrottletoincreaseenginespeed.Whenthe
pedalisreleasedtheenginerunsatlowidle.
RCPH10WHL435AAH3
3-11
