Case 1121F - Two Function Valve

3-CONTROLSANDINSTRUMENTS
Twofunctionvalve[60629755]
Twofunctionvalve-onecontrollever
1.LIFTARMANDBUCKETCONTROL
A.FLOAT(DETENT)-Thisisadetentposition.
WhenintheFLOAT(detent)position,theloader
bucketcanfollowthelevelofthegroundwithout
movementofthecontrollever
B.LOWER
C.HOLD-Theloaderarmsandbucketwillnotmove
whenthecontrolleverisintheHOLDposition.
Whenreleased,thecontrolleverwillautomatically
returntotheHOLDposition.Youmustmanually
movethecontrolleverfromtheFLOATpositionto
theHOLDposition.
D.RAISE
E.DUMP
F.ROLLBACK
RCPH10WHL121BAL1
RCPH10WHL008AAL2
