Case 1121F - Parking Brake

3-CONTROLSANDINSTRUMENTS
Parkingbrake[60628925]
Parkingbrakeswitch
Makesurethemachinehascometoa
completestopbeforeapplyingtheparking
brake.
Theparkingbrakebuttonengagestheparkingbrakeon
thetransmissionoutputshaft.
NOTICE:Theparkingbrakeisaspringapplied,hydraulic
releasedbrakewhichisappliedtothedriveshaft.Itwill
effectivelyholdthemachineinplacewhenusedcorrectly.
RCPH10WHL005BAL1
Engagingtheparkingbrake
Toengagetheparkingbrake,movethegearshiftleverto
neutral("N"),stopthemachineandengagethebrakeby
pushingdownonthetopoftheswitch.Theparkingbrake
willautomaticallyengagewhenthemachineisshutoff.
NOTICE:Afailureintheoperatingprocedureorafailure
intheelectricalorhydraulicfunctioncanresultinabrupt
engagementoftheparkingbrake.Alwayswearyourseat
belt.
Parkingbrakerelease
NOTE:Theservicebrakemustbeatoperatingpressure
beforetheparkingbrakecanbereleasedtomovethema-
chine.Thebrakepressureindicatorlampmustnotbeillu-
minatedwhendisengagingtheparkingbrake.Attempting
tomovethemachinepriortotheservicebrakepressures
beingsufcientcausinglowoperatingpressurecanresult
inprematureparkingbrakepadwear.
3-13
