Case 1121F - Replace Hydraulic Oil Filter (Initial)

7-MAINTENANCE
Replacehydraulicoillter(Initial)[60634950]
WARNING
Pressurizedhydraulicuidcanpenetratetheskinandcausesevereinjuries.
Hydraulicuidisunderextremepressure.Restthebucketorattachmentontheground.Shutthe
engineoff,turnthekeyon,andmovethehydrauliccontrolleverthroughallmovementsseveraltimes
torelieveresidualpressureinthesystem.
Failuretocomplycouldresultindeathorseriousinjury.
W0161A
WARNING
Pressurizeduidcanpenetratetheskinandcausesevereinjuries.
Keephandsandbodyawayfromanypressurizedleak.DONOTuseyourhandtocheckforleaks.Use
apieceofcardboardorpaper.Ifuidpenetratestheskin,seekmedicalattentionimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0158A
Replacethehydraulicoillterwhenthehourmeterregisters100hoursforanewmachineduringtheinitialrun-in
period.Theltershouldbechangedevery1000hoursthereafterormorefrequentlywhenoperatingconditionsare
severe.
Prioroperation:
Keepallnon-authorizedpersonnelclearofthearea.Parkthemachineonlevelgroundinneutralwiththeparking
brakeappliedandtheattachmentloweredtotheground.
1.Releasepressureinthehydraulicsystem.Installthe
transport/servicelinkintothelockposition.
2.Slowlyloosenthellercaponthehydraulicreservoirto
releaseanyresidualpressureinthereservoir.Leaveit
looseduringtheprocedure.
3.Turntheltercounterclockwisetoremove.Lubricate
thegasketandthreadsofthenewlterwithcleanoil
andinstall.Aftertheltermakescontactwiththelter
headtighten1/2to3/4turns.
4.Tightenthecaponthehydraulicreservoir.
RCPH10WHL099BAL1
5.Starttheengineandrunat1000RPM.Haveanas-
sistantcheckforleaksaroundthelterarea.Stopthe
engineandcheckandhydrauliclevel.T opoffifneces-
sary.
RCPH10WHL127AAH2
NOTICE:Neverusealterwrenchtotightenanewlteroninstall.
7-34
