Case 1121F - Battery removal and installation

7-MAINTENANCE
Batteryremovalandinstallation[60637328]
CAUTION
Heavyparts!
Machinebatteriesareextremelyheavy.Makesurethebatteryissupportedsafelyduringtheremoval
process.
Failuretocomplycouldresultinminorormoderateinjury.
C0050A
WARNING
Chemicalhazard!
Whenliftingaplastic-casedbattery,excessivepressureontheendwallscouldcauseacidtospill
throughtheventcaps.Liftaplastic-casedbatterywithabatterycarrierorwithyourhandspositioned
onoppositecornersofthebattery.Alwayswashyourhandsafterhandling.
Failuretocomplycouldresultindeathorseriousinjury.
W0385A
Replacingthebattery
1.Removetheterminalprotectioncaps,disconnectca-
bles(blacknegativeterminals)andthencables(red
positiveterminals).Removetheanti-sulfatepellets.
2.Removethescrews,thewashers,andretainer.Re-
movetheoldbatteries.
3.Installnewbatteriesofthecorrectvoltageandreplace
retainer,washersandscrews.
4.Cleanthecablesandbatteryterminals,andcoatwith
grease.Installnewanti-sulfatepellets.
5.Reconnectpositivecableendstopositiveterminals
rst.Reconnectnegativecableendstonegativeter-
minals.
6.Installtheterminalprotectioncaps.
RCPH11WHL306AAH1
7-105
