Case 1121F - Wheels and Tires

7-MAINTENANCE
Wheelsandtires[60635699]
WARNING
Explosionhazard!
Neverweldonawheel.Weldingcancausestressesthatwillcauseawheeltocrackorbreakunexpect-
edly.Tirescanseparateexplosivelyduringwelding.Alwayshaveaqualiedtiremechanicservice
wheelsandtires.
Failuretocomplycouldresultindeathorseriousinjury.
W0124A
Tireservice
Servicespecications-NormalWorkTireInations
1021FTiretypeFrontpressureRearpressure
26.5X25BiasPly
3.5bar(50.0psi)2.8bar(40.0psi)
26.5X25Radial
4.5bar(65.0psi)3.2bar(47.0psi)
Servicespecications-NormalWorkTireInations
1121FTiretypeFrontpressureRearpressure
26.5X25BiasPly
4.5bar(65.0psi)3.2bar(47.0psi)
26.5X25Radial
5.0bar(73.0psi)3.5bar(51.0psi)
Keepallnon-authorizedpersonnelclearofthearea.Park
themachineonlevelground,inneutralwiththeparking
brakeappliedandtheattachmentloweredtotheground.
Toaddairtoatire:
1.Useanairhosewitharemoteshutoffvalveanda
self-lockingairchuck.Putthetireinarestraining
cage.
2.StandBEHINDthetreadofthetireandmakesure
ALLpersonnelareawayfromthesideofthetire
beforeyoustart.
3.Inatethetiretotherecommendedairpressure.
DONOTinatethetiremorethantherecom-
mendedpressure.
RCPH10WHL149BAL1
Tireorrimservice
Alwayshaveaqualiedtiretechnicianservicethetiresand
rimsforthismachine.Itisrecommendedthatyouhave
thistechnicianinatethetires.T opreventaccidents,usea
restrainingdevice(tireinationcage),correctequipment,
andcorrectprocedure.Explosiveseparationofthetire
(singlepiecerim)orthetireand/orrimparts(multi-piece
rim)cancauseseriousinjuryordeath.
7-43
