Case 1121F - Weight Adjustments and Material Weights

8-SPECIFICATIONS
WeightadjustmentsandMaterialWeights[60639693]
1021FWeightAdjustmentSpecications
Z-BarApplications
TireOptionOperatingWeight
TippingLoadAdjustment
(straight)
TippingLoadAdjustment
(40°turn)
26.5x2512plyL2
-334kg(-736lb)-499kg(-1101lb)-648kg(-1429lb)
26.5x2512plyL3
-129kg(-284lb)-58kg(-129lb)-148kg(-327lb)
Standardcounterweight24399kg(53791lb)19046kg(41989lb)15876kg(35001lb)
NOTE:Unitequippedwith4.2m³(5.50yd³)bucket,MDpinonbucketw/bolt-onedge,26.5R25XHA2Michelintires,
ROPScabwithheaterandairconditioner,lights,fullcounterweight,standardbatteries,frontandrearfenders,full
fueltank,and79kg(175lb)operator.
XRApplications
TireOptionOperatingWeight
TippingLoadAdjustment
(straight)
TippingLoadAdjustment
(40°turn)
26.5x2512plyL2
-334kg(–736lb)-341kg(-751lb)-435kg(-959lb)
26.5x2512plyL3
-129kg(-284lb)-57kg(-126lb)-110kg(-242lb)
Standardcounterweight25688kg(56633lb)16155kg(35616lb)13455kg(29663lb)
NOTE:Unitequippedwith4.2m³(5.50yd³)bucket,MDpinonbucketw/bolt-onedge,26.5R25XHA2Michelintires,
ROPScabwithheaterandairconditioner,lights,fullcounterweight,standardbatteries,frontandrearfenders,full
fueltank,and79kg(175lb)operator.
8-47
