Case 1121F - Drive Belt

7-MAINTENANCE
Drivebelt[60636207]
WARNING
Entanglementhazard!
Alwaysstoptheengineandengagetheparkingbrake,unlessotherwiseinstructedinthismanual,
beforecheckingand/oradjustinganydrivebeltorchain.
Failuretocomplycouldresultindeathorseriousinjury.
W0097A
WARNING
Movingparts!
Installallcovers,panels,andguardsafterservicingorcleaningthemachine.Neveroperatethema-
chinewithcovers,panels,orguardsremoved.
Failuretocomplycouldresultindeathorseriousinjury.
W0135A
Checkthebeltforcorrecttension,wear,anddamage.Wrongbelttensionmaycausebatterychargefailure,engine
overheating,orbeltwear.
Maintenancespecications
VisualcheckEvery10hoursoreveryday
ReplacebeltsEvery1000hours
NOTICE:Iftheenginerunswiththedrivebeltloose,thedrivebeltcanslipandcausetheenginetooverheatorthe
batterytoreceiveinsufcientcharge.
Replacedrivebelt
1.Replacetheaccessorydrivebeltwhenthehourmeter
registers1000hours.Incorrectbelttensionmaycause
batterychargefailure,engineoverheating,orbeltwear.
2.Locatetheaccessorydrivebeltontheleftofthema-
chinedirectlyinfrontofthecoolingbox.Thebeltis
checkedand/orreplacedfromtheleftsideofthema-
chine.
RCPH11WHL294AAH1
7-59
