Case 1121F - Hydraulic oil level

7-MAINTENANCE
Hydraulicoillevel[60634601]
WARNING
Pressurizedhydraulicuidcanpenetratetheskinandcausesevereinjuries.
Hydraulicuidisunderextremepressure.Restthebucketorattachmentontheground.Shutthe
engineoff,turnthekeyon,andmovethehydrauliccontrolleverthroughallmovementsseveraltimes
torelieveresidualpressureinthesystem.
Failuretocomplycouldresultindeathorseriousinjury.
W0161A
Checkthelevelofthehydraulicoiltankevery50hours.
Prioroperation:
Keepallnon-authorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparking
brakeappliedandtheattachmentloweredtotheground.
Servicespecications
TypeofoilAkcelaHydraulicexcavatoruid
1021Ftotalsystemcapacity
250.0l(66.0USgal)
1121Ftotalsystemcapacity
250.0l(66.0USgal)
Fluidlevelcheck
1.Checktheoillevelinthesightgauge,beforeyoustart
theengine.Iftheoiliscold,theleveliscorrectwhen
thetopoftheoilisalignedwiththelowerindicatormark.
Iftheoilisatoperatingtemperature,theleveliscorrect
whenthetopoftheoilisalignedwiththeupperindicator
mark.
RCPH10WHL102AAH1
2.Ifoilisrequired,relieveallpressureinthesystem.
Slowlyloosenthetankcap,andtopoffuntiltheproper
oillevelisreached.Thehydraulicoilllcapislocated
underthecondensercorebehindtheoperator'scab.
RCPH10WHL099BAL2
7-24
