Case 1121F - Loader Functions

4-OPERATINGINSTRUCTIONS
Loaderfunctions[60632809]
Loaderfunctionswitches
Pushdownonthetopoftheswitchtoengagealldetents.
PushonthebottomofswitchforOFF
RCPH10WHL024BAL1
1.Heightcontrol
2.Return-to-travel/oatswitch
3.Returntodig
Return-to-dig
TheReturn-T o-Digfunctionisusedtoautomaticallyre-
turntheloaderbuckettothedigpositionafteryouhave
dumpedtheloaderbucket.T oenabletheReturn-To-Dig
functionpressthetopoftheswitch(3).
RCPH10WHL110BAL2
1.Float
2.Rollbackdetent
Toactuate,movethecontrollever(s)intotheFLOATand
ROLLBACKdetents.Thebucketcontrolleverwillauto-
maticallyreturntotheHOLDpositionandtheloaderarm
willremaininoatwhentheloaderreachestheReturn-
To-Digposition.SeeLoaderAdjustmentsinthismanual
forreturn-to-digAdjustments.
RCPH10WHL119BAL3
1.Floatandrollbackdetent
