3-CONTROLSANDINSTRUMENTS
EXTERIORCONTROLS
Hoodswitchandmasterdisconnect[60630030]
WARNING
Automaticclosure!
Keepyourhandsandbodyandallpersonnelclearofthemachinehoodasitcloses.
Failuretocomplycouldresultindeathorseriousinjury.
W0048A
HoodSwitch
Thehoodswitchislocatedontheleftsideofthemachine.
Thehood,left,andrightsideenginecoversallowaccess
tobothenginesides,aircleanerandcoolers.Alocking
mechanismisprovidedforthehoodswitchcover.Use
themachinekeytoopenandclosethiscover.
1.Insertthekey.Makesuretocompletelyinsertthekey
forproperoperation.
NOTICE:Damagecanoccurtothekeyorlocking
mechanismifkeyisimproperlyinsertedandturned.
2.Afterreleasingthelock,removethekeyandopenthe
cover.
RCPH10WHL425AAH1
3.Thehoodswitchwillautomaticallyraisethehoodon
themachine.Keepalltools,serviceequipment,and
personnelawayfromthehoodwhenitisautomatically
openingandclosing.
RCPH10WHL106AAH2
4.Pushupontheswitchtoraisethehood.Theswitch
willremainintheuppositionforhandsfreeopening.
Toclosethehood,pushdownontheswitch.Asa
builtinsafetymeasure,thedowncontrolmustbeheld
inordertolowerthehood.
RCPH10WHL106AAH3
