3-CONTROLSANDINSTRUMENTS
Manualhoodopening
WARNING
Crushinghazard!
Thehoodisextremelyheavy.Whenmanuallyraisingthehood,usesuitableblockingequipmentand
watchforsharpedgesonmachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0049B
Ifthemachinehasnopowerorthebatteryis
toolowforthehoodswitchtofunction:
NOTICE:Donotusethisproceduretostarttheengine.
Jumpstartingtheenginefromthislocationmaycause
electricaland/orharnessdamagetothemachine.
Thismachineisequippedwitha24Vsystem.Use
appropriateboosterbatteryequipment.
1.Useboosterbatterycablestoprovidepower.Connect
thepositiveboostercabletothecabB+junctionpost,
locatedbehindtherightsidecabaccessdoor.
2.Connectthenegativecabletoaproperground.The
hoodmaynowbeoperatedattheswitch.
RCPH10WHL591AAH4
Ifthemachinehaspower,buttheactuatoris
notfunctioning
Keepallnon-authorizedpersonnelclearofthearea.
Parkthemachineonrm,levelground,andlowerthe
attachment.Putthetransmissioninneutralandapply
theparkingbrake.Turntheengineoff.
1.Removethetwoactuatormountingboltsattheleftrear
ofthemachinejustinfrontofthebatterycompartment.
2.Raisethehoodmanuallywithasuitablehoist.block
forsafety.Donotallowthehoodtoswingoverany
personnel.
RCPH10WHL065BAL5
3-32
