Case 1121F - Joystick operation

6-WORKINGOPERATIONS
Joystickoperation[60633834]
WARNING
Drivinghazard!
Checkallcontrolsandsafetydevicesinasafe,openareabeforestartingwork.
Failuretocomplycouldresultindeathorseriousinjury.
W0248A
WARNING
Drivinghazard!
Alwaysusetheprimarysteeringwhentravelingonapublicroadorhighway.Theleftarmrestmustbe
raisedandinalockedpositionduringtravel.Donotusejoysticksteeringwhentravelingonapublic
roadorhighway.
Failuretocomplycouldresultindeathorseriousinjury.
W0451A
Joysticksteeringcontrollever(optional)
Thejoysticksteeringcontrolleverallowstheloadertobe
operatedusinghandcontrolslocatedontheleftopera-
torseatarmrest.Itallowsforsteeringcapabilitiesatthe
operator’sngertips.Movingtheleverrightorleftsteers
themachineintherightorleftdirection.WhentheJoy-
stickisreleased,theleverwillreturntotheneutralpo-
sitionautomatically.Themachinewillremaininthelast
directionchosen.Forwardandreverseareaccomplished
withtheF-N-Rswitch.Usethejoysticksteeringcontrols
forshortcycle,repetitivehighproductionloadandcarry
operationstoreduceoperatorfatigueandincreaseoper-
atingefciency.
RCIL10WHL188BAL1
1.Joysticksteeringcontrollever
2.Forward-neutral-reverseswitch
3.Kick-downswitch
6-4
