6-WORKINGOPERATIONS
Joysticksteeringarmrestadjustment
Theleftarmrestequippedwithoptionaljoysticksteering
controlscanbeadjustedforoperatorcomfort.
Toadjusttheheightofthearmrest,loosenknob(1).
Lowerorraisethearmrestintothedesiredposition,then
retightentheknob.
Toadjustthearmrestforwardorbackward,loosenknob
(2),thenmovethearmrestbackorforwarduntilitreaches
thedesiredposition.
Retightentheknoboncetheadjustmentiscomplete.For
tiltadjustment,loosenknob(3),thentiltthearmrestinto
thedesiredposition.Retightentheknoboncetheadjust-
mentiscomplete.
RCIL10WHL199BAL2
Lockingarmrestinraisedsafetyposition
1.Tolockthearmintheraisedsafetyposition,raisethe
armtoitsverticalposition.T oblockthearmrest,raise
theredpivot(1).
RCIL10WHL200BAL3
2.Pressthepivot(1)inthedirectionindicatedbythe
arrowinthegureandinsertitintodetent(2).
RCIL10WHL201BAL4
3.Lowerpivot(1).Tounlockthearmrest,pullthepivot
(1)outward,thenlower.
RCIL10WHL202BAL5
