Case 1121F - Support strut for loader lift arm

7-MAINTENANCE
Supportstrutforloaderliftarm[60633940]
Loaderliftarmsupport
WARNING
Crushinghazard!
Ifyouservicethemachinewiththeloaderliftarmsraised,alwaysusethesupportstrut.Removethe
retainingpinandplacethesupportstrutontothecylinderrod.Installtheretainingpinintothesupport
strut.Lowertheliftarmsontothesupportstrut.
Failuretocomplycouldresultindeathorseriousinjury.
W0230A
1.Emptytheloaderbucket,raisetheloaderliftarmsto
approximately2.1m(7ft)andstopengine.
2.Removethesupportstrut(1)fromthestorageposition
byremovingtheretainingbolt.
RCPH11WHL040AAH1
NOTE:Supportstrutintransportposition.
3.Placethesupportstrut(1)ontothecylinderrodwith
theguidelocktab(2)ontopofcylinderandpointing
towardthebucket.
4.Installtheretainingboltentirelyintothesupportstrut
usingallthreads(3).
RCPH11WHL042AAH2
NOTE:Supportstrutandbolt.
7-3
