Case 1121F - Cab Air Louvers

3-CONTROLSANDINSTRUMENTS
CLIMATECONTROLS
Cabairlouvers[60631672]
Mainairlouvers
Thelouversontheconsoledirectairowtowardtheop-
eratorortowardthefrontwindow.
RCPH10WHL056BAL1
Louversontherightandlefthandcabsupportsdirectair
towardtheoperator.
Adjustmentscanbemadetodirecttheairowofthelou-
vers.
RCPH10WHL029BAD2
Recirculationairlouver
Therecirculationairlouversarebehindtheoperator’s
seatnexttotheoor.Whenopen,airisrecirculatedin
thecab.
NOTE:Alwayshavetheselouversopenformaximum
coolingwiththeairconditioningormaximumheatwiththe
heater.
Loosenknob(1)andremovecovertoaccessrecirculation
lter(2).
RCPH10WHL905AAH3
