Auxiliaryforward,neutral,reverse(F-N-R)switch[60632723]
Auxiliaryforward,neutral,reverse(F-N-R)
switchforcontrolleverapplications
1.AuxiliaryjoystickF-N-RSwitch
A.Forward
B.Neutral
C.Reverse
RCPH10WHL118BAL1
ToactuatetheauxiliaryF-N-Rswitchthefollowing
conditionsMUSTbemet:
1.Themachinemustbestopped.
2.Theenginemustberunning.
3.TheauxiliaryF-N-RSwitch(1)mustbeinNeutral(B).
4.Thestandardtransmissioncontrollever(2)mustbein
neutral.
RCPH10WHL116BAL2
5.Theparkingbrakemustbereleased(3).
RCPH10WHL019BAL3
