Joysticksteering[60629623]
WARNING
Drivinghazard!
Ifthehydraulicpilotsaredisengaged,thejoysticksteeringremainsactive.Alwaysdisengagethe
joysticksteeringwhennotinuse.
Failuretocomplycouldresultindeathorseriousinjury.
W0449A
WARNING
Drivinghazard!
Foroptimumcontrol,alwaysusetheprimarysteeringwheelwhenoperatingathighermachinespeeds.
Donotusethejoysticksteeringcontrolwhenoperatingatspeedsabove20km/h(12.4mph).
Failuretocomplycouldresultindeathorseriousinjury.
W0450A
WARNING
Drivinghazard!
Alwaysusetheprimarysteeringwhentravelingonapublicroadorhighway.Theleftarmrestmustbe
raisedandinalockedpositionduringtravel.Donotusejoysticksteeringwhentravelingonapublic
roadorhighway.
Failuretocomplycouldresultindeathorseriousinjury.
W0451A
Joysticksteeringcontrollever(optional)
ThejoysticksteeringcontrolleverandtheForward,Neu-
tral,Reverse(FNR)switchallowtheloadertobeoper-
atedusinghandcontrolslocatedontheleftoperatorseat
armrest.Itallowsforsteeringmovementattheoperator’s
ngertips.
Usethesecontrolsinshortcycle,repetitive,highproduc-
tionloadandcarryoperationstoreduceoperatorfatigue
andincreaseoperatingefciency.Thesystemissetup
sothatthesteeringwheelisalwaysusable(alwayshas
priority)andthejoysticksteeringisdisabledifthesteer-
ingwheelisused.Itmaybepossiblethatthesteering
wheelcouldbeturnedextremelyslowlyandnotdeacti-
vatethejoysticksteering,butforallpracticaloperations
thejoysticksteeringsystemisdeactivatedwhenthesteer-
ingwheelisused.Thearmresthasabuilt-inF-N-Rswitch
andapushbuttonkick-downswitch.
RCIL10WHL188BAL1
1.Joysticksteeringlever
2.F-N-R(forward-neutral-reverse)
3.Kickdownswitch
Forward,Neutral,Reverse(F-N-R)switch
Thisswitchwillallowtheoperatortoputthetransmission
inForward,Neutral,orReverse.T oactivatethisauxil-
iaryF-N-Rswitch,thepropersequencemustbefollowed.
TheprimaryshiftlevermustbeintheNeutralpositionbe-
foreactivatingjoysticksteering.Pushtheswitchforward
toplacethetransmissioninForward,placetheswitchin
themiddlepositiontoplacethetransmissioninNeutral,
andpushtheswitchrearwardtoputthetransmissionin
Reverse.
SeeOperatingInstructionschapterforfurtherinformation.
