Case 1121F - Left-Hand Side Controls; Transmission Controls

3-CONTROLSANDINSTRUMENTS
LEFT-HANDSIDECONTROLS
Transmissioncontrols[60629493]
Transmissioncontrollever
Thetransmissioncontrolleverisusedtoshiftthe
transmissiongearsfromrstthroughfourthgear.Turn
thetransmissioncontrolleverawayfromyoutoselect
ahighergear.Turnthelevertowardyoutoselecta
lowergear.Thiscontrolleverisalsousedtoputthe
transmissioninFORWARD,NEUTRAL,andREVERSE
(F-N-R).
A.MovethecontrolleverawayfromyouforFORWARD.
B.ThecenterpositionofthecontrolleverisNEUTRAL.
C.MovethecontrollevertowardyouforREVERSE.
RCPH10WHL116BAL1
Usingthesteeringcolumntransmission
lever
Allthefollowingstepsarerequiredinordertousethe
steeringcolumntransmissionlever:
1.Servicebrakepressuremustbeatoperatingpressure.
2.Transmissioncontrollevermustbeinneutral.
3.Pushdownonthebottomoftheparkingbrakeswitch
toreleasetheparkingbrakeswitch.
NOTE:IftheparkingbrakewasNOTsetwhenthema-
chinewasturnedOFF ,theparkingbrakeswitchmustbe
cycledatstep3.
4.PlacethetransmissioncontrolleverineitherFOR-
WARDorREVERSEtomovethemachine.
3-14
