Case 1121F - Rotating Beacon Light

7-MAINTENANCE
Rotatingbeaconlight[60637758]
Rotatingbeaconconnection
Therotatingbeaconisanoptionalfeature.Theplug-in
connectionforthebeaconislocatedatthetoprightfrontof
thecab.
RCPH10WHL080BAL1
Auxiliarypoweroutlet
TheAuxiliaryPowerOutletsocket(12V)canbeusedfor
theconnectionofalightingdevicetohelpwithserviceand
maintenanceprocedures.Therearetwoauxiliarypower
outlets,oneintherightcorneroftheoperator’scompart-
ment,andoneintheleftcorneroftheoperator’scompart-
ment.
RCPH10WHL040BAL2
Auxiliarypowerequipmentmountingbracket
Theauxiliarypowerequipmentmountingbracketsarelo-
catedbehindtherightandleftROPSpostcovers.These
bracketsareformountingradios,phones,etc.
Tolocatethebottomofthemountingbracketmeasure
300mm(11.8in)fromthebottomedgeoftheplastic
panel.Tolocatethetopofthemountingbracketmeasure
420mm(16.5in)fromthebottomedgeoftheplasticpanel.
Themountingbracketisapproximately70mm(2.8in)
wide.
RCIL10WHL276BAL3
