Case 1121F - Cab Air Filter - Recirculation Filter

7-MAINTENANCE
Cabairlter-Recirculationlter[60635203]
WARNING
Eyeinjuryhazard!
Wearfullcoveragesafetyglasseswithsidepanelswhenusingcompressedair.Limitairpressureto
200kPa(29psi).
Failuretocomplycouldresultindeathorseriousinjury.
W0162A
Thecabrecirculationairlterislocatedbehindtheoperator’sseat.Cleanthecabairlterswhenthehourmeter
registers250hours.
1.Removetheretainingscrewthatholdstherecirculation
airltercoverinplaceandremovethelter.
2.Checkthelterfordebrisortears.
3.Cleanthere-circulationlterwithdetergentandwater
orreplacewithanewone.Drywithcompressedair.
RCPH10WHL037BAL1
4.Reinstallthelter,andsecuretheaccessltercover.
7-40
