8-SPECIFICATIONS
Dimensionsspecications-1021Fand1121F[60639626]
Thefollowingspecicationsarecommonforall1021F
and1121Fmodelcongurations:
1021Fand1121FCommonSpecications
Feature
Specication
Overallheight(topofexhaust)3545mm(139.6in)
Rearaxleoscillationtotal
24°
Heighttodrawbar
1067mm(42.0in)
Verticalwheeltravel(trunnionfullyoscillated)480mm(18.9in)
LoaderSpeeds
1021F1121F
Loadedraise(rollback@ground)
6.2s6.49s
Loadeddump(@fullheight)
1.3s1.4s
Emptypowerdown2.8s2.8s
Emptyoat
2.6s2.6s
8-14
