8-SPECIFICATIONS
1021FLoader-LiftArmsSpecications
LEEN11T0119FA_11
1021FZ-BarSpecications-3.6m³(4.75yd³)Bucket
Bolt-onEdgeBucket
w/TeethBucket
ISOBucketSpecications
Struck3.11m³(4.07yd³)2.96m³(3.87yd³)
Heaped
3.63m³(4.75yd³)3.49m³(4.56yd³)
Bucketwidth(maximumouter)3195mm(125.8in)3195mm(125.8in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)509.4mm(20.1in)
D(rearangleofdeparture)34°34°
Overallwidthwithbucketguard2990mm(117.7in)2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)6372mm(250.9in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)5676mm(223.4in)5676mm(223.4in)
F(hingepin-fullyraised)4243mm(167.1in)4243mm(167.1in)
G(overall-bucketlevelonground)8774mm(345.4in)8955mm(352.5in)
H(dump-fullyraised,45°dump)3151mm(124.1in)3035mm(119.5in)
J(reach-fullyraised,45°dump)1175mm(46.2in)1313mm(51.7in)
K(reach-2.13m(7.0ft),45°dump)1828mm(72.0in)1918mm(75.5in)
L(digdepth)126.0mm(5.0in)126mm(5.0in)
ISOLoadSpecications
Operatingload8011kg(17661lb)8076kg(17803lb)
Tippingload
Machinestraight
40°turn
19184kg(42293lb)
16021kg(35321lb)
19335kg(42627lb)
16151kg(35607lb)
