Case 1121F - Axle Oil Level

7-MAINTENANCE
Axleoillevel[60635946]
WARNING
Chemicalhazard!
Whenhandlingfuel,lubricants,andotherservicechemicals,followthemanufacturer'sinstructions.
WearPersonalProtectiveEquipment(PPE)asinstructed.Donotsmokeoruseopename.Collect
uidsinpropercontainers.Obeyalllocalandenvironmentalregulationswhendisposingofchemi-
cals.
Failuretocomplycouldresultindeathorseriousinjury.
W0371A
Checktheoillevelinthefrontandrearaxleswhenthehourmeterregisters500hours.
Prioroperation:
Keepallnon-authorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparking
brakeappliedandtheattachmentloweredtotheground.
1021FServicespecications-AkcelaNEXPLORE™uid
Frontaxle
42.0l(44.4USqt)
Rearaxle
42.0l(44.4USqt)
Frontaxlewithaxlecooler
45.7l(48.3USqt)
Rearaxlewithaxlecooler
45.7l(48.3USqt)
Heavydutyfrontaxle62.0l(65.5USqt)
Heavydutyfrontaxlewithcooler65.7l(69.4USqt)
1121FOptionalAxle-AkcelaNEXPLORE™uid
Frontaxle
64.0l(67.6USqt)
Rearaxle
64.0l(67.6USqt)
Frontaxlewithaxlecooler
67.7l(71.5USqt)
Rearaxlewithaxlecooler
67.7l(71.5USqt)
Frontaxlewithdifferentiallock62.0l(65.5USqt)
Frontaxlewithdifferentiallockandaxlecooler65.7l(69.4USqt)
1.Lowerbucket/attachmenttothegroundandinstallthe
transport/servicelinkintothelockposition.
2.Removetheoilplugfromtheaxlecentersectiononthe
frontaxle.Removetheoilplugfromtheendoftherear
axlebeam.Oillevelshouldbelevelwiththebottomof
theplug.
3.AddCaseNexploreoilifrequired.Cleanandinstallthe
plug.
RCPH11WHL228AAH1
7-52
