Case 1121F - Status and Warning Icons

3-CONTROLSANDINSTRUMENTS
Statusandwarningicons[60630461]
6.Stopmasterindicator(Red,critical)
TheStopMasterIndicatorisacritical
warningdisplay.SeeCriticalWarning
Displays.WhentheStopMasterindicator
illuminates,IMMEDIATELYbringthe
machinesafelytoastop,andturnthe
engineOFF .
WARNING
Damagedcomponentscancauseavehicleac-
cident.
IftheSTOPmasterindicatorilluminates,im-
mediatelyandsafelybringthemachinetoa
stopandturntheengineoff.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0050A
RCIL10WHL178BAL1
Thefollowingtablelistscriticalwarningdisplaysthatmayappearontheinstrumentclusterandthecorrectiveaction
thatisrequired.Shouldafaultoccur,acontinuousaudiblealarmwillsoundandtheStopMasterIndicatorwillbe
RED.Awarningmessagewillbedisplayedinthemessagearea.
CriticalWarnings
Display
Description
CorrectiveAction
Engineoil
pressure
Lowengineoil
pressure
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
ContactyourDealer.
Brake
pressure
Lowbrakepressure
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
ContactyourDealer.
Steering
pressure
(w/auxiliary
steering)
Lowsteeringpressure
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
ContactyourDealer.
Coolant
temperature
Highenginecoolant
temperature
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
Checkthecoolantlevelsafterallowingtheengineandthecoolanttocool.
ContactyourDealer.
Hydraulicoil
temperature
Highhydraulicoil
temperature
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
ContactyourDealer.
Transmission
oiltemperature
Hightransmissionoil
temperature
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
ContactyourDealer.
3-36
