Case 1121F - Roll over protective structure

7-MAINTENANCE
Rolloverprotectivestructure[60636006]
WARNING
Roll-overhazard!
Afteranaccident,re,tipover,orrollover,aqualiedtechnicianMUSTreplacetheRoll-OverProtec-
tiveStructure(ROPS)beforereturningthemachinetotheeldorjobsiteoperation.
Failuretocomplycouldresultindeathorseriousinjury.
W0134A
WARNING
Misusehazard!
Yourmachineisequippedwithanoperatorprotectivestructure.DONOTweld,drillholes,attempt
tostraighten,orrepairtheprotectivestructure.Modicationinanywaycanreducethestructural
integrityofthestructure.
Failuretocomplycouldresultindeathorseriousinjury.
W0001B
YourmachineisequippedwithanoperatorProtective
Structure,suchas:RolloverProtectiveStructure(ROPS)
orFallingObjectProtectiveStructure(FOPS).AROPS
maybeacabframeoratwo-postedorfour-postedstruc-
tureusedfortheprotectionoftheoperatortominimize
thepossibilityofseriousinjury.Themountingstructure
andfastenersformingthemountingconnectionwiththe
machinearepartoftheROPS.TheProtectiveStructure
isaspecialsafetycomponentofyourmachine.DONOT
attachanydevicetotheProtectiveStructureforpulling
purposes.DONOTdrillholesintotheProtectiveStructure.
TheProtectiveStructureandinterconnectingcomponents
areacertiedsystem.Anydamage,re,corrosionor
modicationwillweakenthestructureandreduceyour
protection.Ifthisoccurs,theProtectiveStructureMUST
bereplacedsothatitwillprovidethesameprotectionasa
newProtectiveStructure.ContactyourdealerforProtec-
tiveStructureinspectionandreplacement.Theprotective
structureMUSTbereplaced.Themountingorsuspension
fortheProtectiveStructure,operatorseatandsuspension,
seatbeltsandmountingcomponentsandwiringwithinthe
operator’sprotectivesystemMUSTbecarefullyinspected
fordamage.AlldamagedpartsMUSTbereplaced.
RCIL10WHL258BAL1
ROPSdecal
TheLoaderhasaROPSdecalshowingthecerticationof
theROPS,grossweight,approval,regulation,andmodel
numberofthemachine.
CheckandinspecttheROPSstructureandtheseatre-
straintsystemevery500hoursofoperation.
TheROPSdecalislocatedbehindtheoperator’sseat.
7-53
