Case 1121F - Fuel Filter (Initial)

7-MAINTENANCE
Fuellter(Initial)[60634847]
WARNING
Fuelvaporsareexplosiveandammable.
Donotsmokewhilehandlingfuel.Keepfuelawayfromamesorsparks.Shutoffengineandremove
keybeforeservicing.Alwaysworkinawell-ventilatedarea.Cleanupspilledfuelimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0904A
Prioroperation:
Parkthemachineonarm,levelsurface.Lowertheattachmenttotheground.Applytheparkingbrake,andinstall
thetransportservicelinktopreventunexpectedarticulation.
1.Changethefuelprelterwhenthemachinehourmeter
registers100hourswhenthemachineisnewduringthe
initialrun-inperiod.Changethefuelprelterevery500
hoursthereafterormoreoftenifconditionssorequire
oriffuelqualityispoor.Theprelterislocatedonthe
leftsideofthemachine.
2.Removeconnector.Openthedrainvalveonthefuel
prelterbyturningcounterclockwisetwoorthreeturns.
3.Drainthewaterand/orcontaminantsfromtheprelter
intoasuitablecontaineruntilcleanfuelows.Donot
allowfueltospillonengineorground.
4.Turntheltercounterclockwisetoremove.
5.Replacewithanewltercartridge,turningclockwise
untilthecartridgemeetsthelterhead.Handtighten
rmlyinplace.Donotuseawrenchtotighten.Replace
connectoratbottomoflter.
RCPH11WHL294AAH1
6.T obleedairfromthesystem,usethepumpatthetop
ofthelter.Pumpuntilfuelowswithoutairbubbles.
RCPH11WHL244AAH2
7-31
