7-MAINTENANCE
Changinghydraulicoillter
CAUTION
Springundertension!
Inthefollowingsteps,thehightensionspringmustbecarefullyunloaded.Maintainhands-oncontrol
ofthebreakerbarfortheentireprocedure.Weareyeprotection.
Failuretocomplycouldresultinminorormoderateinjury.
C0072A
9.Removeandreplacethehydraulicoillterwhenreplac-
inghydraulicoil.Thelterislocatedunderthereservoir
cover(2).Removescrewsfromcover.
RCPH11WHL265AAH4
10.Usecareascoverisspringloaded.Removespring
andO-ring.
RCPH11WHL266AAH5
11.Removespring(3)andO-ring(4).
RCPH11WHL267AAH6
