4.Locatethereturntotraveltarget(2)oppositetheprox-
imityswitchandthentightenittothetargetmounting
plate.Nextadjusttheproximityswitchouttowardthe
targetuntilandairgapof3.5-5mm(0.1-0.2in)is
obtained.Locktheproximityswitchinpositionwithits
jamnut.Torquethejamnutto5lbft.
5.Thelocationoftheheightcontroltarget(4)withinits
slotinthetargetmountingplatewilldeterminetheauto-
maticstoppingheightoftheliftarmsastheyareraised.
Thehigherthetargetispositionedinitsslotinthetarget
mountingplate,thelowertheliftarmswillautomatically
stopastheyareraised.Positionthetargetpertheta-
ble.Tightenthetargetinthisposition.
6.Thelocationofthereturntotraveltarget(2)withinits
slotinthetargetmountingplatewilldeterminewhere
theliftarmswillautomaticallystopwhiletheyarelow-
ered.Thehigherthistargetislocatedinitsslotinthe
targetmountingplatethelowertheliftarmswillauto-
maticallystopastheyarelowered.Positionthetarget
perthetable.Tightenthetargetinthisposition.
7.Makesuretheproximityswitchandallthemounting
boltsaretight.Starttheengine.Setthedetentswitch
totheonposition,andsetthereturntotravel/oatde-
tentswitchtothereturntotravelposition.Raisethe
liftarmstoapproximatelythehorizontalposition.Put
theloadercontrolleverintheraiseposition,andver-
ifythattheelectromagnetholdsitinthatpositionuntil
theheightcontroltargetpassesinfrontoftheproximity
switch.Next,withtheliftarmsstillraised,puttheloader
controlleverinthelowerposition,andverifythatthe
electromagnetholdsitinthatpositionuntilthereturnto
traveltargetpassesinfrontoftheproximityswitch.Po-
sitionthebucketatontheground.Shutthemachine
OFF.
RCPH11WHL2812
MachineAApproximate
resultingreturn
totravelhingepin
height
BApproximateresulting
heightcontrolhinge
pinheight
1021FZ-Bar
67.0mm(2.6in)540.0mm(21.3in)75.0mm(3.0in)4140.0mm(163.0in)
1021FXR
50.0mm(2.0in)693.0mm(27.3in)60.0mm(2.4in)4140.0mm(163.0in)
1121FZ-Bar
59.0mm(2.3in)653.5mm(25.7in)76.0mm(3.0in)4220.0mm(166.0in)
1121FXR
46.0mm(1.8in)694.0mm(27.3in)65.0mm(2.6in)4220.0mm(166.0in)
