8-SPECIFICATIONS
1021FCylinderSpecications
Liftcylinder
Borediameter
177.8mm(7.00in)
Roddiameter
114.3mm(4.50in)
Stroke780.6mm(30.73in)
Steercylinder
Borediameter
88.71mm(3.493in)
Roddiameter
50.8mm(2.00in)
Stroke518.0mm(20.39in)
Dumpcylinder
Borediameter
203.2mm(8.00in)
Roddiameter
127.0mm(5.00in)
Stroke581.9mm(22.91in)
InstrumentationGauges
SpeedometerEngineCoolantTemperature(ECT)Gearposition
TachometerHydraulicoiltemperatureTransmissionmodes
HourmeterTransmissionoiltemperature
Travelselected(FNR)
OperatorEnvironment
ROPScabwithheater
KeystartArticulatedpowersteeringwithtilt
Adjustablesuspensionseat
Singlelever2-spoolloadercontrolCupholder
Coathook
Interiorrearviewmirror
Singlebrakepedal
Storagetray
DomelightFrontandrearwindshieldwashers
Exteriorrearviewmirrors
Front(intermittent)andrearwipers52mm(2in)retractableseatbelt
Rightandleftsteps/platforms
Fireextinguisherbracket
HydraulicSpecications
Pump1
Closedcenteredpressure/owcompensated
Variabledisplacement
100.0cm³/rev(6.1in³/rev)
190l/min(50.2USgpm)@2000RPM
Pump2
Closedcenteredpressure/owcompensated
Variabledisplacement
85.0cm³/rev(5.19in³/rev)
162l/min(42.8USgpm)@2000RPM
Loaderauxiliarysteering
hydraulicorbitalcenter-pivotarticulatingw/on-demand
oilow
Filtration
10-micron,fullowreplaceablecartridgesonreturnline,
conditionindicatorlightforlter
8-4
