8-SPECIFICATIONS
LEEN11T0119FA_12
1021FZ-BarSpecications-4.2m³(5.5yd³)Bucket
Bolt-onEdgeBucket
w/TeethBucket
ISOBucketSpecications
Struck3.63m³(4.75yd³)3.49m³(4.56yd³)
Heaped
4.20m³(5.49yd³)4.06m³(5.31yd³)
Bucketwidth(maximumouter)3195mm(125.8in)3195mm(125.8in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)509.4mm(20.1in)
D(rearangleofdeparture)34°34°
Overallwidthwithbucketguard2990mm(117.7in)2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)6372mm(250.9in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)5800mm(228.4in)5800mm(228.4in)
F(hingepin-fullyraised)4243mm(167.0in)4243mm(167.0in)
G(overall-bucketlevelonground)8892mm(350.1in)9073mm(357.2in)
H(dump-fullyraised,45°dump)3075mm(121.1in)2959mm(116.5in)
J(reach-fullyraised,45°dump)1265mm(49.8in)1404mm(55.3in)
K(reach-2.13m(7.0ft),45°dump)1887mm(74.3in)1974mm(77.7in)
L(digdepth)126mm(5.0in)126mm(5.0in)
ISOLoadSpecications
Operatingload7938kg(17500lb)8001kg(17639lb)
Tippingload
Machinestraight
40°turn
19046kg(41989lb)
15878kg(35001lb)
19193kg(42313lb)
16002kg(35278lb)
