8-SPECIFICATIONS
LEEN11T0119FA_13
1021FZ-BarSpecications-4.4m³(5.75yd³)BucketFlatBottomwithBlade
Bolt-onEdgeBucket
ISOBucketSpecications
Struck3.80m³(4.97yd³)
Heaped
4.40m³(5.75yd³)
Bucketwidth(maximumouter)2980mm(117.3in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)
D(rearangleofdeparture)34°
Overallwidthwithbucketguard2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)
Turninganglefromcenter40°
Totalturningangle
80°
E(fullyraisedwithspillguard)5942mm(233.9in)
F(hingepin-fullyraised)4253mm(167in)
G(overall-bucketlevelonground)8979mm(353.5in)
H(dump-fullyraised,45°dump)3019mm(118.9in)
J(reach-fullyraised,45°dump)1332mm(52.5in)
K(reach-2.13m(7.0ft),45°dump)1930mm(76in)
L(digdepth)126mm(5in)
ISOLoadSpecications
Operatingload7841kg(17286lb)
Tippingload
Machinestraight
40°turn
18857kg(41572lb)
15682kg(34572lb)
8-19
