Case 1121F - Page 331

8-SPECIFICATIONS
LEEN11T0119FA_14
1021FZ-BarSpecications-4.4m³(5.75yd³)BucketFlatBottomwithTeeth
w/TeethBucket
ISOBucketSpecications
Struck3.65m³(4.77yd³)
Heaped
4.23m³(5.53yd³)
Bucketwidth(maximumouter)2980mm(117.3in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)
D(rearangleofdeparture)34°
Overallwidthwithbucketguard2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)
Turninganglefromcenter40°
Totalturningangle
80°
E(fullyraisedwithspillguard)2339mm(5942in)
F(hingepin-fullyraised)4243mm(167.1in)
G(overall-bucketlevelonground)9133mm(359.6in)
H(dump-fullyraised,45°dump)2920mm(115in)
J(reach-fullyraised,45°dump)1450mm(57.1in)
K(reach-2.13m(7.0ft),45°dump)2001mm(78.8in)
L(digdepth)126mm(5.0in)
ISOLoadSpecications
Operatingload8009kg(17657lb)
Tippingload
Machinestraight
40°turn
19219kg(42370lb)
16018kg(35315lb)
8-21
