8-SPECIFICATIONS
LEEN11T0120FA6
1021FXRSpecications-4.2m³(5.5yd³)Bucket
Bolt-onEdgeBucket
w/TeethBucket
ISOBucketSpecications
Struck3.63m³(4.75yd³)3.49m³(4.56yd³)
Heaped
4.20m³(5.49yd³)4.06m³(5.31yd³)
Bucketwidth(maximumouter)3195mm(125.8in)3195mm(125.8in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)509.4mm(20.1in)
D(rearangleofdeparture)34°34°
Overallwidthwithbucketguard2990mm(117.7in)2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)6372mm(250.9in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)6382mm(251.3in)6382mm(251.3in)
F(hingepin-fullyraised)693mm(27.3in)693mm(27.3in)
G(overall-bucketlevelonground)9410mm(370.5in)9591mm(377.6in)
H(dump-fullyraised,45°dump)3657mm(144in)3541mm(139.4in)
J(reach-fullyraised,45°dump)1278mm(50.3in)1416mm(55.8in)
K(reach-2.13m(7.0ft),45°dump)2357mm(92.8in)2451mm(96.5in)
L(digdepth)129mm(5.1in)129mm(5.1in)
ISOLoadSpecications
Operatingload6727kg(14831lb)6778kg(14942lb)
Tippingload
Machinestraight
40°turn
16178kg(3566lb)
13454kg(29662lb)
16298kg(35930lb)
13556kg(29885lb)
8-25
