Case 1121F - Page 337

8-SPECIFICATIONS
LEEN11T0120FA7
1021FXRSpecications-4.4m³(5.75yd³)BucketFlatBottomwithBlade
Bolt-onEdgeBucket
ISOBucketSpecications
Struck3.80m³(4.97yd³)
Heaped
4.40m³(5.75yd³)
Bucketwidth(maximumouter)2980mm(1173in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)
D(rearangleofdeparture)34°
Overallwidthwithbucketguard2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)
Turninganglefromcenter40°
Totalturningangle
80°
E(fullyraisedwithspillguard)6523mm(256.8in)
F(hingepin-fullyraised)4824mm(189.9in)
G(overall-bucketlevelonground)9498mm(373.9in)
H(dump-fullyraised,45°dump)3600mm(141.7in)
J(reach-fullyraised,45°dump)1345mm(52.9in)
K(reach-2.13m(7.0ft),45°dump)2403mm(94.6in)
L(digdepth)129mm(5.1in)
ISOLoadSpecications
Operatingload6615kg(14583lb)
Tippingload
Machinestraight
40°turn
15943kg(35149lb)
13229kg(29165lb)
8-27
