Case 1121F - Page 339

8-SPECIFICATIONS
LEEN11T0120FA8
1021FXRSpecications-4.4m³(5.75yd³)BucketFlatBottomwithTeeth
w/TeethBucket
ISOBucketSpecications
Struck3.65m³(4.77yd³)
Heaped
4.23m³(5.53yd³)
Bucketwidth(maximumouter)2980mm(117.3in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)
D(rearangleofdeparture)34°
Overallwidthwithbucketguard2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)
Turninganglefromcenter40°
Totalturningangle
80°
E(fullyraisedwithspillguard)6524mm(256.8in)
F(hingepin-fullyraised)4825mm(190in)
G(overall-bucketlevelonground)9651mm(380in)
H(dump-fullyraised,45°dump)3502mm(137.9in)
J(reach-fullyraised,45°dump)1462mm(57.6in)
K(reach-2.13m(7.0ft),45°dump)2481mm(97.7in)
L(digdepth)129mm(5.1in)
ISOLoadSpecications
Operatingload6765kg(14914lb)
Tippingload
Machinestraight
40°turn
16267kg(35862lb)
13530kg(29829lb)
8-29
