8-SPECIFICATIONS
1121FLoader-LiftArmsSpecications
LEEN11T0119FA_19
1121FZ-BarSpecications-4.0m³(5.2yd³)Bucket
Bolt-onEdgeBucket
w/TeethBucket
ISOBucketSpecications
Struck3.46m³(4.53yd³)3.31m³(4.33yd³)
Heaped
4.01m³(5.24yd³)3.87m³(5.06yd³)
Bucketwidth(maximumouter)3195mm(125.8in)3195mm(125.8in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)509.4mm(20.1in)
D(rearangleofdeparture)34°34°
Overallwidthwithbucketguard2990mm(117.7in)2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)6372mm(250.9in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)5960mm(234.6in)5960mm(234.6in)
F(hingepin-fullyraised)4443mm(174.9in)4443mm(174.9in)
G(overall-bucketlevelonground)8967mm(353in)9148mm(360.2in)
H(dump-fullyraised,45°dump)3299mm(129.9in)3183mm(125.3in)
J(reach-fullyraised,45°dump)1157mm(45.5in)1296mm(51.0in)
K(reach-2.13m(7.0ft),45°dump)1965mm(77.4in)2054mm(80.9in)
L(digdepth)118mm(4.6in)118mm(4.6in)
ISOLoadSpecications
Operatingload8961kg(19756lb)9031kg(19910lb)
Tippingload
Machinestraight
40°turn
21150kg(46627lb)
17923kg(39512lb)
21310kg(46980lb)
18062kg(39820lb)
8-31
