8-SPECIFICATIONS
LEEN11T0119FA_111
1121FZ-BarSpecications-5.0m³(6.53yd³)BucketFlatBottomwithBlade
Bolt-onEdgeBucket
ISOBucketSpecications
Struck4.40m³(5.75yd³)
Heaped
5.0m³(6.54yd³)
Bucketwidth(maximumouter)3175mm(125in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)
D(rearangleofdeparture)34°
Overallwidthwithbucketguard2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)
Turninganglefromcenter40°
Totalturningangle
80°
E(fullyraisedwithspillguard)6199mm(244in)
F(hingepin-fullyraised)4442mm(174.9in)
G(overall-bucketlevelonground)9289mm(365.7in)
H(dump-fullyraised,45°dump)3092mm(121.7in)
J(reach-fullyraised,45°dump)1403mm(52.2in)
K(reach-2.13m(7.0ft),45°dump)2119mm(83.4in)
L(digdepth)119mm(4.7in)
ISOLoadSpecications
Operatingload8748kg(19285lb)
Tippingload
Machinestraight
40°turn
20735kg(47714lb)
17495kg(38571lb)
8-35
