Case 1121F - Page 347

8-SPECIFICATIONS
LEEN11T0119FA_112
1121FZ-BarSpecications-4.8m³(6.27yd³)BucketFlatBottomwithTeeth
w/TeethBucket
ISOBucketSpecications
Struck4.01m³(5.25yd³)
Heaped
4.63m³(6.06yd³)
Bucketwidth(maximumouter)3195mm(125.8in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)
D(rearangleofdeparture)34°
Overallwidthwithbucketguard2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)
Turninganglefromcenter40°
Totalturningangle
80°
E(fullyraisedwithspillguard)6120mm(240.9in)
F(hingepin-fullyraised)4442mm(174.9in)
G(overall-bucketlevelonground)9300mm(366.1in)
H(dump-fullyraised,45°dump)3085mm(121.5in)
J(reach-fullyraised,45°dump)1412mm(55.6in)
K(reach-2.13m(7.0ft),45°dump)2124mm(83.6in)
L(digdepth)118mm(4.7in)
ISOLoadSpecications
Operatingload8921kg(19668lb)
Tippingload
Machinestraight
40°turn
21099kg(46516lb)
17843kg(39336lb)
8-37
