Case 1121F - Page 349

8-SPECIFICATIONS
LEEN11T0120FA13
1121FXRSpecications-4.0m³(5.2yd³)Bucket
Bolt-onEdgeBucket
w/TeethBucket
ISOBucketSpecications
Struck4.46m³(4.53yd³)3.31m³(4.33yd³)
Heaped
4.01m³(5.24yd³)3.87m³(5.06yd³)
Bucketwidth(maximumouter)3195mm(125.8in)3195mm(125.8in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)509.4mm(20.1in)
D(rearangleofdeparture)34°34°
Overallwidthwithbucketguard2990mm(117.7in)2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)6372mm(250.9in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)6377mm(251.1in)6377mm(251.1in)
F(hingepin-fullyraised)4860mm(191.3in)4860mm(191.3in)
G(overall-bucketlevelonground)9374mm(369.1in)9555mm(376.2in)
H(dump-fullyraised,45°dump)3717mm(146.3in)3600mm(141.7in)
J(reach-fullyraised,45°dump)1200mm(47.2in)1338mm(52.7in)
K(reach-2.13m(7.0ft),45°dump)2335mm(91.9in)2430mm(95.7in)
L(digdepth)118mm(4.7in)118mm(4.7in)
ISOLoadSpecications
Operatingload7882kg(17378lb)7941kg(17506lb)
Tippingload
Machinestraight
40°turn
18596kg(40997lb)
15765kg(34756lb)
18732kg(41298lb)
15881kg(35012lb)
